Tmax560 Standard

Tmax560 Standard Specs

Start Option	Petrol Electric
Front Brake	Petrol Disc
Category	Petrol Scooter
Maximum Power	Petrol 47 bhp
Engine	Petrol 562 cc

Yamaha Tmax560 Standard Key Highlights

The Yamaha Tmax560 Standard is a Petrol CVT variant of the Yamaha Tmax560 lineup. Checkout Yamaha Tmax560 Standard Price in the Thailand. View Tmax560 Standard Latest Promos, Colors, Review, Images and more at Zigwheels.

Read More Read Less

Yamaha Tmax560 Standard Engine Details

Tmax560 Standard variant is powered by a 562 cc Petrol Engine with Fuel Injection system, It has a 2-Cylinder, 4-Stroke, Liquid Cooled, DOHC, 4-Valves.

Yamaha Tmax560 Standard Transmission

Tmax560 Standard is paired with a Variable Speed CVT transmission.

Tmax560 Standard Performance

Tmax560 Standard 562 cc engine offers 47 bhp of power and 55.7 Nm of torque.

Yamaha Tmax560 Standard Competitors

In the Thailand, Tmax560 Standard has a bunch of competitors, one of which is Yamaha Tmax Tech Max Standard.

Tmax560 Standard Technical Specifications

• Engine & Performance
• Electrical
• Fuel & Ignition
• Dimension
• Chassis & Suspension
• Wheels & Tyres
• Gear & Transmission

• Exhuast Pipes Single Exhaust
• Compression Ratio 10.9:1
• Injection Type Fuel Injection
• Cooling System Liquid Cooled
• Clutch Type Wet, Multi-Plate
• Drive Type Belt Drive
• Bore X Stroke 70.0 mm x 73.0 mm
• Lubrication System Dry Sump
• Valve Configuration DOHC
• Engine Type 2-Cylinder, 4-Stroke, Liquid Cooled, DOHC, 4-Valves
• Valves Per Cylinder 4
• No. Of Cylinder 2
• No. Of Strokes 4-Stroke
• Displacement 562 cc
• Maximum Power 47 bhp
• Maximum Torque 55.7 Nm
• RPM at Maximum Power 7500 rpm
• RPM at Maximum Torque 5250 rpm

• Tail Lamp LED
• Adjustable Headlights Yes
• Head Lamp LED
• Battery Voltage 12 V
• Indicator Light Yes

• Fuel Type Gasoline
• Fuel Supply System Fuel Injection
• Ignition Type TCI
• Start Option Electric

• Wheelbase 1575 mm
• Height 1415 mm
• Curb Weight 218 kg
• Length 2195 mm
• Width 780 mm
• Seating Capacity 2
• Category Scooter
• Seat Height 800 mm
• Ground Clearance 135 mm

• Seat Type Dual Stepped
• Front Suspension Inverted Telescopic Fork
• Rear Suspension Shock Absorber

• Rear Wheel Size R15
• Front Wheel Size R15
• Rear Tyre 160/60 R15
• Front Tyre 120/70 R15
• Tyre Type Radial, Tubeless

• Transmission Type CVT
• Gear Box Variable Speed

Tmax560 Standard Features

• Safety & Security
• Console
• Differentiating Features
• Brake

• Engine Check Warning Yes
• Side Reflectors Yes
• Shutter Lock Yes
• Pass Switch Yes
• Leg Guards No
• ABS Yes
• Launch Control No

• Speedometer Digital
• Oil Change Indicator Yes
• Display Screen Yes
• Odometer Digital
• Tachometer Yes
• Fuel Gauge Digital
• Tripmeter Yes

• Height Adjustable Seats No

• Front Brake Disc
• Rear Brake Disc

Compare Tmax560 Standard with other Variants

• Petrol

• Tmax560 Standard

  ฿539,000 OTR Price

  Base Variant Features
  • Petrol
  • CVT
  • ABS
  • Pass Switch
  • Display Screen
  • Oil Change Indicator
  • Adjustable Headlights
  • Engine Check Warning
  • Side Reflectors
  • Shutter Lock
  • Indicator Light
  • Tripmeter
  • Tachometer

  View More VIEW MARCH PROMOS

Compare Tmax560 Standard With Similar Bikes

Tmax560 Standard ฿539,000 Yamaha Tmax560 Compare	Tmax Tech Max Standard ฿569,000 Yamaha Tmax Tech Max Compare
Engine 562	562
Maximum Power 47	47
Start Option Electric	Electric
Category Scooter	Scooter
Front Brake Disc	Dual Disc
Compare Now	Tmax560 vs Tmax Tech Max

Compare Similar Bikes

Gallery of Tmax560 Standard

• exterior
• color

Yamaha Tmax560 Standard Exterior Images

Yamaha Tmax560 has 9 images of its exterior, top Yamaha Tmax560 2025 exterior images include Slant Front View Full Image, Front View Full Image, Slant Rear View Full Image, Left Side View Full Image, Right Side Viewfull Image, Head Light View, Rear Tyre, Speedometer, Seat Storage Side View.

Read More Read Less

•
•
•
•
•
•
•
•
•

Tmax560 Exterior Images

Yamaha Tmax560 Standard Colors

Yamaha Tmax560 is available in 2 different colors - Sword Gray, Icon Black.

•
•

• Sword Gray
• Icon Black

Yamaha Tmax560 Colors
